Bulk Seattle Self contained Ceiling / wall surface mounted IP65 4W 20 m Automatic self test

Article number B3D14601
zoom_in Zoom

  • Description

    Slim bulkhead with an effective luminous flux of 190 lm. Guaranteed lifetime of 75,000 hours and suitable for wall and ceiling mounting. With automatic self-test for time saving. IP65 protection degree. Comes complete with pictograms.

    Application
    Suitable for waterproof applications such as swimming pools, food processing plants, sports complexes and other locations subject to extreme conditions

    Type
    Bulk Seattle

  • Downloads

    descriptionDownload Spacingtabellen descriptionDownload Handleiding descriptionDownload Handleiding Testprocedures

  • Specifications

    • Brand Taurac Plus
    • Article number B3D14601
    • Kind Bulkhead
    • Mounting method Surface mounting/recessed mounting
    • Function Escape route lighting/signage
    • Suitable for labelling type Sticker
    • Type of indicator Single-sided
    • With pictogram Yes
    • Monitoring equipment Automatic self test
    • Wiring system Continuous circuit/emergency circuit
    • Power supply system Peripheral (individual battery)
    • Battery quality Lithium-ions
    • Lamp type LED not exchangeable
    • Lamp holder None
    • Housing material Plastic
    • Housing colour White
    • Material cover Plastic, transparent
    • Voltage type AC/DC
    • Nominal voltage (V) 220 - 240
    • Type of control gear LED operating device current-controlled
    • Light distributor Diffuser lens/optic/panel
    • Energy efficiency class of the light source according to EU regulation 2019/2015 Not required
    • Rated life time L70/B50 at 25 °C (h) 75000
    • Degree of protection (IP) IP65
    • Impact strength IK07
    • Protection class I
    • Rated ambient temperature according to IEC 62722-2-1 (°C) 0 - 40
    • Max. system power (W) 4
    • Rated luminous flux according to IEC 62722-2-1 (lm) 125
    • Luminous flux in standby mode (lm) 150
    • Colour temperature (K) 6000 - 6000
    • Power factor 0,90
    • Recognition distance (m) 20
    • Nominal operation time (h) 75000 - 75000
    • Width (mm) 110
    • Height/depth (mm) 60
    • Length (mm) 345
    • Built-in height/depth (mm) 30
    • Type of wiring Ending
    • Number of poles 4
    • Conductor cross section (mm²) 0,50
    • Connection type Plug-in connection
    • Rechargeable Yes
    • Unit Piece
    • Warranty (months) 36
Article number B3D14601

Bulk Seattle Self contained Ceiling / wall surface mounted IP65 4W 20 m Automatic self test
